How to Remove DeLonghi Coffee Grinder Parts: A Deep Disassembly Guide

It was a cold Tuesday morning in my kitchen. I needed coffee badly. But my DeLonghi just made a sad hum. The faint smell of old coffee dust filled the air. I knew a quick brush would not fix this. I had to go deep.

Taking a grinder apart is not the same as a quick wash. Cleaning is just dusting the top. But learning how to remove DeLonghi coffee grinder parts is a full teardown. You must do this for bigger problems.

Here is exactly when you need a deep teardown:

• Motor repair: Fixing a burnt or dead motor.
• Swapping burrs: Changing dull metal for sharp, fresh parts.
• Fixing jammed gears: Clearing a rock-hard bean stuck deep inside.

My goal today is simple. I will show you my exact steps to take your machine apart safely. The worst feeling is hearing a loud snap because you broke a hidden plastic tab. I made those annoying mistakes early on so you do not have to. Let’s get your grinder fixed.

Essential Tools for Disassembly

I remember sitting at my kitchen table one rainy Saturday. My grinder was totally jammed. I tried to pop it open with a dull butter knife. That was a bad idea. I just scratched the smooth plastic and bent the knife. It felt awful.

Before you learn exactly how to remove DeLonghi coffee grinder parts, you must get the right gear. You do not need a huge toolbox. Just grab these four basic items to do the job right:

• Small Phillips head screwdriver: You need this to take out the long screws hidden deep in the base.
• Flathead screwdriver: This is strictly for prying the tight plastic clips. Go slow here. If you push too fast, the hard plastic makes a loud cracking sound. You do not want to break those tabs.
• Needle-nose pliers: Deep inside the machine, you will find tiny wires and stiff metal springs. My thick fingers could never reach them. Pliers grab those parts easily and safely.
• A small parts tray: Grinder screws are super tiny. They love to fall, bounce on the floor, and hide under the fridge. I lost two screws my very first time. A small bowl or magnetic tray keeps them totally safe.

Having these tools ready keeps the job fun and stress-free.

Step 1: How to Remove the Bean Hopper

Empty your coffee beans first. Turn the main dial past the ‘Coarse’ setting until you feel a click. Lift the clear plastic bin straight up. If it does not move, look for small safety screws inside.

One sunny Friday, I stood in my messy kitchen. My grinder was clogged with oily dark roast beans. The smell was strong. I tried to pull the top off to wash it. It was stuck hard. I soon learned that knowing how to remove DeLonghi coffee grinder parts starts right here.

This is a deep teardown, not a quick rinse.

Follow these exact steps to do it right:

• Empty the bowl: Pour out all loose beans. A flying bean makes a huge mess on the floor.
• Turn the top dial: Twist the hopper past the ‘Coarse’ mark. Wait for a firm click. This action frees the locked plastic tabs.
• Find the safety screws: Do not yank the plastic. On models like the KG79 or KG89, look deep inside. You might see tiny silver safety screws. Use your small Phillips head screwdriver here. Put those tiny screws in your parts tray.
• Lift it free: Pull the clear top straight up. It will slide out smoothly.

If you pull hard and it fights you, stop at once. I broke a plastic tab on my first try years ago. That loud crack broke my heart. Take your time here.

Step 2: Removing the Upper and Lower Burrs

I stood at my cold kitchen counter last winter. My hands were covered in gritty coffee dust. The plastic top was off. Now came the real work. The top burr is simple to take out. But the bottom one is a beast. Most quick guides skip it totally.

If you truly want to learn how to remove DeLonghi coffee grinder parts, you must get both metal pieces out.

Here is how I do it without going crazy:

• The Upper Burr: Look for a small metal wire handle. Grab it tight. Twist the whole piece to the left. Then, just pull it straight up. It should pop right out.
• The Lower Burr: Look deep inside the machine. You will see a nut right in the center. Wrap a thick rag around the sharp metal burr to hold it still. Use a small wrench or your pliers. Turn the center nut to the left to break it loose.
• Pull the deep part out: With the nut gone, wiggle the bottom burr straight up. Thick, sticky coffee mud will hold it down. Just keep pulling up slowly.

How to check for bad wear and tear: Once the burrs are out, wipe the metal clean. Run your thumb gently across the teeth. Do they feel round, smooth, and flat? If yes, the metal is too dull. Good burrs feel sharp, like a fresh pocket knife. Dull parts smash your beans and ruin the taste. If they are smooth, it is time to buy new ones.

Step 3: Removing the Outer Casing (The “Teardown”)

It was a hot Sunday afternoon in my garage. Sweat stung my eyes. I had the burrs out. But the dark plastic shell was still in my way. This is always the scary part. You want to open the case, but you fear breaking it.

If you want to master how to remove DeLonghi coffee grinder parts safely, you must master the plastic clips.

Here is my safe method for the outer shell:

• Find the hidden screws: Turn your grinder upside down. Look closely near the rubber feet. You will see deep holes. Screws hide down in there. Grab your small Phillips head screwdriver. Take them all out and put them in your tray.
• Pop off the front knob: Look at the main grind dial on the front panel. Just grab it tight and pull it straight toward your chest. Do not turn it. It slides right off the metal pin. Put it in your safe tray.
• Pry the shell apart: This is the tricky step. Find the line on the back where the plastic meets. Slide your flathead screwdriver gently into that tiny crack. Push it in just a little. Wiggle the tool up and down. Do not twist it hard.

I twisted a flathead too hard a few years ago. A hidden plastic clip snapped with a loud crack. I jumped right out of my chair. To avoid that mini heart attack, just go slow. You will hear gentle pops as the small clips let go. Once it feels loose, pull the plastic sides apart with your bare hands.

Step 4: Accessing the Motor and Circuitry

It was late Thursday night at my workbench. The dark plastic shell was finally off. A weird smell hit me right away. It smelled like old stale coffee and hot metal. This is the deep heart of the machine. To truly master how to remove DeLonghi coffee grinder parts, you must face the wires.

Do not let the wires scare you. Just go slow.

Here is how I check the motor safely:

• Take off the mounting plate: You will see a main plate covering the motor. Find the small screws holding it down. Keep your hand steady. Take them out and drop them in your parts tray. Lift the plate straight off.
• Spot the big capacitor: Inside, you will see a messy web of colored wires. You will also see a thick round tube. That is the capacitor. Do not touch the shiny metal tips. It can hold a charge and give you a tiny zap! Use your needle-nose pliers to gently move any thin motor wires out of your way.
• Hunt for dust and burns: Shine a bright light deep inside the motor housing. I once found a huge pile of coffee dust packed in there. It was blocking the fan totally. Brush it all out gently. Next, check the wires. Look closely for black burn marks or melted plastic spots. If the wires look dark and crispy, that is why your grinder stopped working.

How to Remove a Clogged Ground Chute

It was a busy Monday morning. I wanted a strong espresso. The grinder hummed loudly, but no coffee came out. Zero. It just made an angry buzzing sound. The motor was totally fine. The path was just physically blocked.

If you want to master how to remove DeLonghi coffee grinder parts, you must check the ground chute. This is the short tunnel where coffee drops into your plastic bin. Dark, oily beans clog this tunnel very fast. The dust packs together and turns into a hard brick of coffee mud.

Here is how I clear that tunnel out safely:

• Find the chute: Look right below the bottom burr area. You will see a small square plastic tunnel leading out.
• Take out the screws: Some models use two small screws to hold this piece in place. Grab your small Phillips head screwdriver. Take them out and put them in your tray.
• Pull the tunnel: Slide the plastic chute straight out toward you. Wiggle it gently if it feels stuck.
• Clear the hard brick: I use a simple wooden toothpick to poke the hard coffee plug. It is oddly satisfying to watch that dark block fall out. Do not use a sharp metal knife for this. You will scratch the smooth inner plastic walls. Scratches grab dust and make future clogs happen much faster.

Reassembly: Putting it All Back Together

It was a quiet Wednesday evening at my kitchen table. My hands smelled like cold metal and old roast. The table was a total mess of loose parts. Taking things apart is the fun part. But putting them back together can make you sweat.

Once you learn exactly how to remove DeLonghi coffee grinder parts, you must put them back right. If you rush, you will just have to take it apart all over again.

Here is my safe routine for putting it back together:

• The “Reverse Order” rule: I just work backward. I grab the very last part I took off. I put that piece back first. I start with the internal motor plate. Then I gently snap the dark plastic shell back on. You will hear a loud, crisp click when the plastic sides lock tight.
• Aligning the burr settings: This step is huge. I rushed this once. My dial said “Fine,” but huge chunks of beans came out! Before you lock the clear top hopper, check the upper burr. Make sure the small plastic guide dot lines up perfectly with the correct mark on the base. It must match the front dial.
• Test before you tighten: Do not put those deep bottom screws in yet! I always plug the machine in for a quick test spin first. I push the power button. If I hear a smooth, fast hum, I smile with big relief. Then, I unplug the cord and put the final hidden screws in.

Reassembly: Putting it All Back Together

It was a quiet Wednesday evening at my kitchen table. My hands smelled like cold metal and old roast. The table was a total mess of loose parts. Taking things apart is the fun part. But putting them back together can make you sweat.

Once you learn exactly how to remove DeLonghi coffee grinder parts, you must put them back right. If you rush, you will just have to take it apart all over again.

Here is my safe routine for putting it back together:

• The “Reverse Order” rule: I just work backward. I grab the very last part I took off. I put that piece back first. I start with the internal motor plate. Then I gently snap the dark plastic shell back on. You will hear a loud, crisp click when the plastic sides lock tight.
• Aligning the burr settings: This step is huge. I rushed this once. My dial said “Fine,” but huge chunks of beans came out! Before you lock the clear top hopper, check the upper burr. Make sure the small plastic guide dot lines up perfectly with the correct mark on the base. It must match the front dial.
• Test before you tighten: Do not put those deep bottom screws in yet! I always plug the machine in for a quick test spin first. I push the power button. If I hear a smooth, fast hum, I smile with big relief. Then, I unplug the cord and put the final hidden screws in.

Once your machine is humming smoothly again, make sure your settings are dialed in by revisiting my step-by-step beginner’s guide to using a DeLonghi coffee grinder.

Safety Warnings

It was a sunny Saturday morning on my back porch. I was drinking my fresh coffee. I looked down at a small paper cut on my thumb. That tiny sting reminded me of a very harsh truth. If you want to learn how to remove DeLonghi coffee grinder parts, you must be careful.

To stay totally safe while taking your machine apart, watch out for these three big dangers:

• Kiss your warranty goodbye: Let us be honest here. Once you pry that dark plastic shell open, your factory warranty is dead. If your grinder is brand new, stop right now. Call the company and send it back. But if yours is five years old like mine was, you have nothing to lose at all.
• Watch those sharp metal teeth: Those burrs are not smooth. They are made of tough, cold steel meant to crush hard beans. I grabbed the bottom burr with my bare hand once. I squeezed it way too hard. It sliced right into my thumb. Always use a thick shop rag or tough work gloves when you pull those sharp metal pieces out.
• Do not pinch the power cord: This is a very sneaky trap. When you snap the outer shell back on, look closely at the thick black power wire. Make sure it sits totally flat in its little plastic groove. I once pinched the cord hard between two plastic walls. When I plugged it into the wall outlet, it sparked loudly! It scared the life out of me. Always check your wires twice before you lock the case down tight.

Conclusion

It was a quiet Sunday night. I sat down at my clean kitchen counter. The sweet smell of fresh coffee filled the room. The grinder hummed like a happy cat. Fixing it myself felt so good. I smiled and took a hot sip.

Now you know exactly how to remove DeLonghi coffee grinder parts. You just have to decide your next step.

When to Do It Yourself

• Fixing clogs: Do the work yourself if you just have a hard block of coffee mud.
• Changing burrs: Swapping dull metal parts for sharp ones is an easy home repair.
• Deep cleaning: It is free and quite fun if you take your time and follow the steps.

When to Call a Pro

• Burning smells: Stop if you see thick smoke or smell burning wires.
• Motor death: Do not mess with the deep motor if you hate electrical stuff.
• New machines: If the warranty is still active, just mail it back to the brand.

My Final Maintenance Tip Here is my best secret to save you time. You do not need to do this huge teardown very often. Just brush the top metal pieces clean every single week. Do not let dark, oily beans sit inside the hopper for months. A little daily care keeps your grinder running perfectly for years.

Frequently Asked Questions

Why is my top bean hopper stuck?

You must turn the big dial past the coarse mark. This frees the tight lock. Knowing how to remove DeLonghi coffee grinder parts saves time. Give it a try now!

Can I wash the steel burrs with water?

No do not wash them with water. Water makes the cold steel rust fast. Just use a dry brush to clean the dust. A clean machine makes a great cup of dark roast.

When should I change the metal burrs?

Change them when the top teeth feel round and smooth. Sharp teeth crush beans well. Dull parts just smash them and ruin the taste. Fresh parts fix this fast.

How do I clear a hard bean clog?

Find the short ground chute down deep inside. Take out the small screws. Use a wood stick to push the hard block out. Learning to clear clogs helps so much.

Is it safe to open the dark case?

Yes it is safe if you pull the plug first. Go slow and use a small flat tool. Do not snap the hard tabs. Read our full guide to learn all the safe steps today.
